| Foot Print | 25 x 25 x 51 cm (11.8″ x 11.8″ x 20″) |
| Build Volume | 7.45 x 13.25 x 18 cm (2.9″ x 5.1″ x 7.1″) |
| XY Pixel Size | 52 μm |
| Z Layer Thickness | >25 μm |
| Speed | 20 – 45 mm /hr (depending on resin, layer thickness and cross-sectional area) |
| Weight | 23.2 lb / 10.5 Kg |
| Light Source | 84W collimated 405nm LEDs for high precision (powered at 45W to ensure a long lifetime) |
| Pattern Projection | 2K LCD |
| Resin Container | PSP-D (Drum type PSP container) |
| Software | Browser-based control |
| Wireless Printing | Via Wi-Fi repeater |
| Resins | 3rd party compatible including NextDent |
| Zero Calibration | Auto z zeroing |
| System Requirement | Windows |
| Linear Stage | THK Industrial Grade High Precision module |
| Voltage | 100-240V |
| Maximum Power Consumption | 65W |
